Category Archives: HTML

HTML – Hide the broken icon when the is not yet loaded

Updated @ 2015-10-12: The following snippet could get rid of the broken icon without using CSS and JS.

<svg class="card__image" xmlns="http://www.w3.org/2000/svg" xmlns:xlink="http://www.w3.org/1999/xlink" viewBox="0 0 1920 500" preserveAspectRatio="xMidYMid slice">
  <image width="1920" height="500" xlink:href="" ng-href="{{ image.href }}"></image>
</svg>



Thanks Wouter De Loose.



i have the following <svg> in an AngularJS template and the image source would be assigned by the controller which loaded the image info from a .json file.

<svg class="card__image" xmlns="http://www.w3.org/2000/svg" xmlns:xlink="http://www.w3.org/1999/xlink" viewBox="0 0 1920 500" preserveAspectRatio="xMidYMid slice">
  <image width="1920" height="500" xlink:href="{{ image.href }}"></image>
</svg>



It works fine on my local machine but when i put it on a webserver. There would be a flash of the broken image before the image is loaded. Continue reading HTML – Hide the broken icon when the is not yet loaded

Advertisements

Offset the anchor link for sticky header

If you have a sticky header (Position fixed header on the top of the html page), your anchor link with CSS ID would not work as you expected. The target section would be covered by the position fixed header.

You can use the following CSS to offset the fixed header height.

/* The target CSS ID with :before pseudo class */
.offset:before {
  display: block;
  content: " ";
  height: 150px;      /* Give height of your fixed element */
  margin-top: -150px; /* Give negative margin of your fixed element */
  visibility: hidden;
}



Done =)

Reference: Offsetting Anchor Hash Tag Links To Adjust For Fixed Header

CSS – Number rating widget

I have a HTML form which has radio inputs range from 1 to 5:

<form>
  <input type="radio" name="num" value="1" checked>1
  <input type="radio" name="num" value="2">2
  <input type="radio" name="num" value="3">3
  <input type="radio" name="num" value="4">4
  <input type="radio" name="num" value="5">5
</form>



I want to convert it into a rating widget. I found a very good post with an example to convert radio inputs into a star rating widget.

Code by Stephen Morley – A star rating widget using CSS

But instead of rating by stars, i would like to create a number rating widget. So i modified the example a bit. First, create a image as follow.
icon_number_widget
Continue reading CSS – Number rating widget

HTML – Disable auto scaling on iPhone Safari when switching from portrait to landscape

For iPhone users, when you are viewing a website on Safari and switch the screen orientation from portrait to landscape, you will find that the content of the page will be scaled automatically to fit the screen width. This maybe a nice feature but probably not good for responsive design.

To disable the auto scaling, you can add the following meta on your HTML inside the <head> tag.

<meta name="viewport" content="width=device-width; initial-scale=1.0; maximum-scale=1.0; user-scalable=0" />



A drawback is the above meta will disable the user scaling as well. For more information, please refer to the reference link below.

Done =)

Reference: StackOverflow – How can I disable MobileSafari’s content scalling on orientation change?

HTML – Include .html using jQuery

There are some methods like Server Side Includes which allow us to include other HTML files into a web page on a webserver like

<!-- #include virtual="./common.html" -->

But this technique require server side setting and may be not supported by some web hosting.

Another way to include .html in a web page is using jQuery insertion.
Continue reading HTML – Include .html using jQuery

HTML – Prevent the Skype browser plugin from converting the phone number

If your browser is bundled with the Skype plugin, it will automatically wrap the phone number with Skype format. This can be avoided by adding a invisible text anywhere in the phone number.

<!-- Orginal -->
<div>852 12345678</div>
<!-- Prevent the Skype plugin to work -->
<div>852 1234<span style="display:none;">_</span>5678</div>



Done =)

Reference: 1066internet – Prevent Skype from converting a phone number

Styling checkbox and radio button with CSS and Javascript

I want to style the form elements such as radio button, checkbox or selection list. Google shows me a very good tutorial written by Ryan Fait.
Las Vegas Web Design – Checkboxes, Radio Buttons, Select Lists, Custom HTML Form Elements

In the above tutorial, those form elements will be replaced by a span element. It works great. Only 1 minor problem which is those span elements could not align well. So i made some change on the CSS. Here is my example.
Continue reading Styling checkbox and radio button with CSS and Javascript
